Introduction

If you have a GoPro camera or another device that records MP4 videos and for some unexpected reason your video is corrupted for various reasons, it’s possible to recover the video without sound! It’s not ideal, but it’s better than losing everything.

First, reinsert the card into the device and see if it can repair it by itself. An SOS message will appear, press any other button to let it attempt the repair. If it doesn’t work… continue with the following steps.

Prerequisites

You will need:

Repair Script

Here is the downloadable version above, but if you want to see its content:

(fix.pl)

  1
  2
  3
  4
  5
  6
  7
  8
  9
 10
 11
 12
 13
 14
 15
 16
 17
 18
 19
 20
 21
 22
 23
 24
 25
 26
 27
 28
 29
 30
 31
 32
 33
 34
 35
 36
 37
 38
 39
 40
 41
 42
 43
 44
 45
 46
 47
 48
 49
 50
 51
 52
 53
 54
 55
 56
 57
 58
 59
 60
 61
 62
 63
 64
 65
 66
 67
 68
 69
 70
 71
 72
 73
 74
 75
 76
 77
 78
 79
 80
 81
 82
 83
 84
 85
 86
 87
 88
 89
 90
 91
 92
 93
 94
 95
 96
 97
 98
 99
100
101
102
103
104
105
106
107
108
109
110
111
112
113
114
115
116
117
118
119
120
121
122
123
124
125
126
127
128
129
130
131
132
133
134
135
136
137
138
139
140
141
142
143
144
145
146
147
148
149
150
151
152
153
154
155
156
157
158
159
160
161
162
163
164
165
166
167
168
169
170
171
172
173
174
175
176
177
178
179
180
181
182
183
184
185
186
187
188
189
190
191
192
193
194
195
196
197
198
199
200
201
202
203
204
205
206
207
208
209
210
211
212
213
214
215
216
217
218
219
220
221
222
223
224
225
226
227
228
229
230
231
232
233
234
235
236
237
238
239
240
241
242
243
244
245
246
247
248
249
250
251
252
253
254
255
256
257
258
259
260
261
262
263
264
265
266
267
268
269
270
271
272
273
274
275
276
277
278
279
280
281
282
283
284
285
286
287
#!/usr/bin/perl
my $infile = shift(@ARGV);
my $outfile = $infile . ".restore.mp4";

my $ctts_offset=0;
my $width = 1280;
my $height = 720;
my $framerate = 25;
my $i, $val;

#
# Parse command line options for options
#
for($i=0; $i<@ARGV; $i++) {
	if ($ARGV[$i] =~ /-ctts/) {
		$ctts_offset = $ARGV[++$i];
	}
	if ($ARGV[$i] =~ /-reso/){
		$val = $ARGV[++$i];
		if ($val eq '720p30' || $val eq 'ntscr2') {
			$width = 1280;
			$height = 720;
			$framerate = 30;
		} elsif ($val eq '720p60' || $val eq 'ntscr3') {
			$width = 1280;
			$height = 720;
			$framerate = 60;
		} elsif ($val eq '960p30' || $val eq 'ntscr4') {
			$width = 1280;
			$height = 960;
			$framerate = 30;
		} elsif ($val eq '1080p30' || $val eq 'ntscr5') {
			$width = 1920;
			$height = 1080;
			$framerate = 30;
		} elsif ($val eq '480p60' || $val eq 'ntscr1') {
			$width = 848;
			$height = 480;
			$framerate = 60;
		} elsif ($val eq '720p60' || $val eq 'palr3') {
			$width = 1280;
			$height = 720;
			$framerate = 50;
		} elsif ($val eq '960p30' || $val eq 'palr4') {
			$width = 1280;
			$height = 960;
			$framerate = 25;
		} elsif ($val eq '1080p30' || $val eq 'palr5') {
			$width = 1920;
			$height = 1080;
			$framerate = 25;
		} elsif ($val eq '480p60' || $val eq 'palr1') {
			$width = 848;
			$height = 480;
			$framerate = 50;
		} elsif ($val eq '720p30' || $val eq 'palr2') {
			$width = 1280;
			$height = 720;
			$framerate = 25;
		} elsif ($val eq '960p48' || $val eq '96048HD2') {
			$width = 1280;
			$height = 960;
			$framerate = 48;
		} else {
			printf("Error - resolution $val not supported. Trying default ".$height."p"."$framerate\n");
		}
	}

}

open INFILE, "<", $infile or die("Cannot open $infile for reading\n");
binmode INFILE;


print ("\nAttempting to fix $infile\n\n");

#disable screen buffering
$|=1;

#
# read data section, find video frames
#

my $n, $size, $type, $buff, $framecount, @ptrs, @szs, $offset, $pmdat;

#
# Skip looking for mdat, find frames by brute force
#


$framecount = 0;

#set delimiter to look for 6-byte value indicating AVC frame start
$/ = pack ("C*", (0x00, 0x00, 0x00, 0x02, 0x09));

printf("Found frame        at         ");
while ($buff = <INFILE>)  {
	printf("\b\b\b\b\b\b\b\b\b\b\b\b\b\b\b\b\b\b%06d at %08x", $framecount, (tell INFILE) - 5);
	$ptrs[$framecount] = (tell INFILE)-5; #adjust to start of code
	if ($framecount > 0) {
		$szs[$framecount-1] = $ptrs[$framecount] - $ptrs[$framecount-1];
		#print ("size:  ".$szs[$framecount-1]."  \n");
	}
	$framecount++;
}

# throw away last one since it triggered on EOF
$framecount--;
pop(@ptrs);

#set beginning of mdat pointer based on 1st found frame
$pmdat=$ptrs[0]-8;


if ($framecount == 0){
	printf("\b\b\b\b\b\b\b\b\b\b\b\b\b\b\b\b\b\b\b\b\b\b\b\b\b\b\b\b\b\b\b\b");
	printf("No frames found. Quitting.            \n");
	close INFILE;
	exit;
} else {
	print ("\n");
}


open OUTFILE, ">", $outfile or die("Cannot open $outfile for writing\n");
binmode OUTFILE;
print ("Opened file $outfile for writing\n\n");


$min=0xffffffff;
$max=0x0;
foreach(@szs){
	if ($_ > $max) {$max = $_}
	if ($_ < $min) {$min = $_}
}


printf("Found %d (%x) frames, or approx %ds of video at %dfps\n", $framecount, $framecount, $framecount / $framerate, $framerate);
printf("   min size %x, max size %x\n", $min, $max);
printf("   from %x, to %x\n", $ptrs[0], $ptrs[$framecount-1]);



#
# Rebuild Header
#

my $hdrsize, $i, $moov, $stbl ;

#calculate size
#17 B per frame V, 17 Bpf A, plus overhead
$hdrsize = (34 * $framecount) + 2500;
$hdrsize = int ($hdrsize / 0x8000) + 1;
if ($hdrsize % 2 == 0) {
	$hdrsize ++; # always make header size an odd multiple of 0x8000
}
$hdrsize = $hdrsize * 0x8000;

# calculate adjustment for new header size
$offset = $hdrsize - $pmdat ;

printf("Calculated header size of 0x%x \n",$hdrsize);
printf("Using ctts offset of $ctts_offset\n");
printf("Using $width x $height @ $framerate fps\n");

# ftyp
print OUTFILE pack("NA4A4NA4A4NN",0x20,'ftyp','avc1',0,'avc1','isom',0,0);

#stbl
$stbl = pack ("NA4NN",0xf9,'stsd',0,0x01);
$stbl .= pack ("NA4NNNNNNnnNNNCCCA21C11CCC",0xe9,'avc1',0,1,0,0,0,0,$width,$height,0x480000,0x480000,0,0,1,0x15,'Ambarella AVC encoder',0,0,0,0,0,0,0,0,0,0,0,0x18,0xff,0xff);
$stbl .= pack ("NA4NN",0x10,'pasp',0,0);
$stbl .= pack ("NA4N8",0x28,'clap',$width,1,$height,1,0,1,0,1);
if ($height == 1080) {
	$stbl .= pack ("NA4N15C3",0x47,'avcC',0x014d0028,0xffe10030,0x274d0028,0x9a6280f0,0x044fcb80,0x8800001f,0x48000753,0x07430005, 0xb8e00019,0xbfd5de5c,0x686000b7,0x1c000337,0xfabbcb87,0xc2211458,0x01000428,0xee,0x3c,0x80);
} elsif ($height == 480) {
	$stbl .= pack ("NA4N15C3",0x47,'avcC',0x014d401e,0xffe10030,0x274d401e,0x9a6281a8,0x7b602200,0x7d200,0x03a981d0,0x8007a180, 0x0044aa57,0x7971a100,0x0f430000,0x8954aef2,0xe1f08845,0x16000000,0x01000428,0xee,0x3c,0x80);
} elsif ($height == 960) {
	$stbl .= pack ("NA4N15C3",0x47,'avcC',0x014d0028,0xffe10030,0x274d0028,0x9a6280a0,0x0f360220,0x7d20,0x1d4c1d,0x0c0016e3, 0x800066ff,0x577971a1,0x8002dc70,0x000cdfea,0xef2e1f08,0x84516000,0x01000428,0xee,0x3c,0x80);
}  else {
	$stbl .= pack ("NA4N15C3",0x47,'avcC',0x014d0028,0xffe10030,0x274d0028,0x9a6280a0,0x0b760220,0x7d20,0x1d4c1d,0x0c003d0a, 0x0112a9,0x5de5c686,0x1e8500,0x8954ae,0xf2e1f088,0x451e0000,0x01000428,0xee,0x3c,0x80);
}
$stbl .= pack ("NA4N3",0x14,'btrt',0,0,0);
$stbl .= pack ("NA4N4",0x18,'stts',0,1,$framecount,90090/$framerate);
$stbl .= pack ("NA4NN",8*$framecount  + 0x10, 'ctts', 0, $framecount);
if ($height == 1080) {
	for ($i=0;$i < $framecount;$i++){
		$stbl .= pack ("NN",1,0x0bbb);
	}
} elsif ( $framerate == 60) {
	for ($i=$ctts_offset;$i < $framecount + $ctts_offset;$i++){
		if (($i  %6 == 0) || ($i %6 == 3)) {
			$stbl .= pack ("NN",1,0x1199);
		} elsif (($i  %6 == 1) || ($i %6 == 5)) {
			$stbl .= pack ("NN",1,1);
		} else {
			$stbl .= pack ("NN",1,0);
		}
	}
} else {
	for ($i=$ctts_offset;$i < $framecount + $ctts_offset;$i++){
		if ($i % 3 == 0) {
			$stbl .= pack ("NN",1,0x2331);
		} else {
			$stbl .= pack ("NN",1,0);
		}
	}
}
$stbl .= pack ("NA4N5",0x1c,'stsc',0,1,1,1,1);
$stbl .= pack ("NA4N3",4*$framecount + 0x14, 'stsz',0,0,$framecount);
for ($i=0;$i < $framecount;$i++){
	$stbl .= pack ("N",$szs[$i]);
}
$stbl .= pack ("NA4N2",4*$framecount + 0x10, 'stco',0,$framecount);
for ($i=0;$i < $framecount;$i++){
	$stbl .= pack ("N",$ptrs[$i] + $offset);
}
#fake stss because I don't know how to re-calculate it
$stbl .= pack ("NA4N3",0x14,'stss',0,1,1);
$stbl .= pack ("NA4N",$framecount + 0xc,'sdtp',0);
if ($height == 1080) {
	for ($i=0;$i < $framecount;$i++){
		$stbl .= pack ("C",0);
	}
} else {
	for ($i=0;$i < $framecount;$i++){
		if ($i % 3 == 0) {
			$stbl .= pack ("C",0);
		} else {
			$stbl .= pack ("C",0x08);
		}
	}
}
#moov
print OUTFILE pack("NA4",$hdrsize-0x20,'moov');
print OUTFILE pack ("NA4N25",0x6c,'mvhd',0,0,0,0x015f90,2700000 / $framerate / 0x1d * $framecount, 0x010000, 0x01000000, 0, 0, 0x010000,0,0,0,0x010000,0,0,0,0x40000000,0,0,0,0,0,0,3);
print OUTFILE pack ("NA4",0x180,'udta');
if ($height == 960) {
	print OUTFILE pack ("NA4N30",0x80,'AMBA',0x040003,0x01030f00,0x04,0x1776,0x02bf20,0xb71b00,0xb71b00,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0x0100);
} elsif ($height == 1080) {
	print OUTFILE pack ("NA4N30",0x80,'AMBA',0x100009,0x01010800,0x04,0x0bbb * (3-($framerate/30)),0x02bf20,0xb71b00,0xb71b00,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0x0100);
} else {
	print OUTFILE pack ("NA4N30",0x80,'AMBA',0x100009,0x01030f00,0x04,0x0bbb * (3-($framerate/30)),0x02bf20,0x7a1200,0x7a1200,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0x0100);
}
print OUTFILE pack ("NA4N60",0xf8,'free',(0)x60);
print OUTFILE pack ("NA4",0x16a + length($stbl), 'trak');
print OUTFILE pack ("NA4N19n4",0x5c,'tkhd',0x07,0,0,1,0,2700000 / $framerate / 0x1d * $framecount,0,0,0,0,0x10000,0,0,0,0x10000,0,0,0,0x40000000,$width,0,$height,0);
print OUTFILE pack ("NA4",0x24,'edts');
print OUTFILE pack ("NA4N5",0x1c,'elst',0,1,0x015f90 / 0x1d * $framecount, 90090/$framerate,0x10000);
print OUTFILE pack ("NA4",0x44, 'tapt');
print OUTFILE pack ("NA4Nn4",0x14,'clef',0,$width,0,$height,0);
print OUTFILE pack ("NA4Nn4",0x14,'prof',0,$width,0,$height,0);
print OUTFILE pack ("NA4Nn4",0x14,'enof',0,$width,0,$height,0);
print OUTFILE pack ("NA4", 0x9e + length($stbl), 'mdia');
print OUTFILE pack ("NA4N6", 0x20, 'mdhd', 0,0,0,0x015f90,0x015f90 / 0x1d * $framecount,0);
print OUTFILE pack ("NA4N2A4N3CA13", 0x2e, 'hdlr', 0,0, 'vide',0,0,0,0xd,'Ambarella AVC');
print OUTFILE pack ("NA4",0x48 + length ($stbl), 'minf');
print OUTFILE pack ("NA4N3", 0x14, 'vmhd', 1,0,0,);
print OUTFILE pack ("NA4",0x24,'dinf');
print OUTFILE pack ("NA4N2",0x1c,'dref',0,1);
print OUTFILE pack ("NA4N",0xc,'url ',1);
print OUTFILE pack ("NA4", 0x8+length($stbl),'stbl');
print OUTFILE $stbl;


print OUTFILE pack ("NA4",$hdrsize - tell OUTFILE, 'free');

for ($i=$hdrsize - tell OUTFILE; $i>0; $i--) {
	print OUTFILE pack ("C",0);
}

#
# Copy data over
#

print OUTFILE pack ("NA4",unpack ("%123d*" , pack( "d*", @szs)) + 13,'mdat');
seek INFILE, $pmdat + 8, 0;
$framecount=0;
printf("Copying  frame       ...");
while ($buff = <INFILE>)  {
	printf("\b\b\b\b\b\b\b\b\b%06d...", $framecount++);
	print OUTFILE $buff;
}
print("\nDone.\n");

close OUTFILE;
close INFILE;

Usage

Put the fix.pl file in the same folder as your corrupted/unreadable video. Then launch the script from the terminal like this:

1
perl ./fix.pl <video>.MP4 -reso <resolution> -ctts <value>
  • video: specify the name of the video file to repair
  • resolution: indicate if it’s PAL or NTSC, followed by the resolution identifier (look behind the GoPro camera, there are r1, r2…). For NTSC in r3, it would be ntscr3.
    • possible resolutions: palr1, palr2, palr3, palr4, palr5, ntscr1, ntscr2, ntscr3, ntscr4, ntscr5 and 96048HD2
  • ctts: Start with 0, then increase by 1 if the video quality doesn’t meet your expectations

For my part, I was able to recover a 1.4GB video like this:

 1
 2
 3
 4
 5
 6
 7
 8
 9
10
11
12
13
14
15
> perl ./fix.pl GOPR0029.MP4 -reso palr2 -ctts 0

Attempting to fix GOPR0029.MP4

Found frame 027878 at 53fffffb
Opened file GOPR0029.MP4.restore.mp4 for writing

Found 27878 (6ce6) frames, or approx 1115s of video at 25fps
   min size d09, max size 4e3fa
   from 8004, to 53ffc644
Calculated header size of 0xf8000
Using ctts offset of 0
Using 1280 x 720 @ 25 fps
Copying  frame 027878...
Done.

Unfortunately, the last few minutes that weren’t written to the card are missing, and also the audio since it’s not possible to recover the sound with this method.

Your working video will have the same name as the original in the same location where the video is located, with ‘restore’ added to the name.

References

Last updated 12 Sep 2012, 23:16 CEST. history
